36NiCrMo16 Alloy Steel Bar
Txuj: ASTM / DIN & BS EN / JIS
Daim ntawv pov thawj: ISO9001, BV, SGS, CTI, ROHS
1. Qib: 36NiCrMo16 steel puag ncig bar
2. Loj: 8mm -3000mm
3. Txuj: ASTM / DIN & BS EN / JIS
4. Ntawv pov thawj: ISO9001, BV, SGS, CTI, ROH
Tshuaj muaj pes tsawg leeg
Qib | C | Mn | P | S | Si | Cr | Ni | Mo |
1.6773 | 0.32- 0.39 | 0.50- 0.80 | 0.025 max | 0.025 max | 0.40 max | 1.60- 2.00 | 3.60- 4.10 | 0.25- 0.45 |
Mechanical Properties
Txheej txheem | Txoj kab uas hla (mm) | Tensile zog Rm (Mpa) | Yield zog Rp 0.2 (Mpa) | Elongation A5 (%) | Thaj tsam txo qis C (%) | Kev cuam tshuam Value Kv (J) Kiv nqwb | Hardness (HB) |
QUENCHED THIAB TEMPERED | 16 max | 1250-1450 | 1050 min | 9 feeb | 40 feeb | / | 368-424 |
QUENCHED THIAB TEMPERED | 16- 40 | 1250- 1450 | 1050 min | 9 feeb | 40 feeb | 30 feeb | 368-424 |
QUENCHED THIAB TEMPERED | 40- 100 | 1100- 1300 | 900 min | 10 feeb | 45 feeb | 35 feeb | 324-382 |
Muaj Qhov Loj
Round bar: Txoj kab uas hla (mm) Max 800mm; Ntev (mm) Max 12000mm.
Phaj: Thickness (mm) Max 800mm; Dav (mm) Max 2300mm; Ntev (mm) Max 12000mm.
Qhov xwm txheej: Txias dov (kos) Tsawg dua lossis sib npaug li 50mm, Kub dov Tsawg dua lossis sib npaug rau 12-250mm, Kub forged Ntau dua lossis sib npaug li 50mm.
Daim ntawv thov
Aircraft Landing Gear, Automotive, Roj thiab Gas Drilling, Forging, sov thiab txias sib sau, Tshuab Tsev, Hloov Systems, lub zog kis tau tus mob gears thiab shafts, hnyav luag hauj lwm shafts, zog, qag, spindles, couplings, pins, chucks, pwm ect.
Packing & Delivery
Ntim Cov Lus Qhia
Export txheem pob, bundled los yog yuav tsum tau.
Qhov loj me ntawm lub thawv yog hauv qab no:
20ft GP: 5.8m (ntev) x 2.13m (dav) x 2.18m (siab)
40ft GP: 11.8m (ntev) x 2.13m (dav) x 2.18m (siab)
40ft HG: 11.8m (ntev) x 2.13m (dav) x 2.72m (siab)
FAQ
Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?
A: Peb yog Hoobkas.
Q: Koj lub sijhawm xa khoom ntev npaum li cas?
A: Feem ntau nws yog 5-10 hnub yog tias cov khoom muaj nyob hauv Tshuag. los yog nws yog 15-20 hnub yog tias cov khoom tsis nyob hauv Tshuag, nws yog raws li qhov ntau.
Q: Koj puas muab cov qauv? puas yog dawb los yog ntxiv?
A: Yog, peb tuaj yeem muab cov qauv dawb tab sis tsis them tus nqi thauj khoom.
