20CrMnTi iav Steel Bar
Yield Strength (MPA): Ntau dua lossis sib npaug rau 850
Elongation (δ5 / feem pua): Ntau dua lossis sib npaug li 10 feem pua
Txo hauv Cheeb Tsam (ψ / feem pua): Ntau dua lossis sib npaug li 45 feem pua
20CrMnTi yog cov hlau carburized nrog kev ua tau zoo thiab muaj zog hardenability. Tom qab carburizing thiab quenching, nws muaj ib qho nyuaj thiab hnav-resistant nto thiab ib tug tawv chaw, siab low-temperature impact toughness, medium weldability, thiab zoo machinability tom qab normalizing. Nws yog ib qho kev hloov steel ntawm 18CrMnTi, uas yog dav siv los ua carburized qhov chaw. Hauv kev lag luam tsheb thiab tsheb laij teb, nws yog siv los ua ib qho tseem ceeb carburized nrog ib feem ntawm tsawg dua 30 hli, uas tuaj yeem tiv taus kev kub ceev, nruab nrab lossis hnyav, cuam tshuam thiab kev sib txhuam, xws li iav, ncej, iav nplhaib, iav ncej, lub ntsiab ncej ntawm zawv zawg kabmob, crosshead, claw clutch, worm, thiab lwm yam.
Chemical Composition thiab Mechanical Properties(Hauv Quenched & Tempered State)
Khoom siv | 20 CrMnTi | ||
Tshuaj muaj pes tsawg leeg | Mechanical Properties (Hauv Quenched & Tempered State) | ||
C | 0.17-0.23 | Tensile zog (MPA) | Ntau dua lossis sib npaug rau 1080 |
Si | 0.17-0.37 | Yield zog (MPA) | Ntau dua lossis sib npaug li 850 |
Mn | 0.80-1.10 | Elongation (δ5 / feem pua) | Ntau dua lossis sib npaug li 10 feem pua |
Cr | 1.00-1.30 | Kev txo qis hauv cheeb tsam (ψ / feem pua) | Ntau dua lossis sib npaug li 45 feem pua |
Ti | 0.04-0.10 | Kev cuam tshuam (J) | Ntau dua lossis sib npaug li 55 |
P | Tsawg dua lossis sib npaug rau 0.030 |
Hardness |
Tsawg dua lossis sib npaug rau 217HB
|
S | Tsawg dua lossis sib npaug rau 0.030 | ||
V | ------- | ||
Zoo sib xws steel qib & Sib npaug steel cov ntaub ntawv
Teb chaws USA | Nyiv | Gemany | Askiv | Fabkis | Thoob ntiaj teb | Suav |
ASTM & AISI & SAE | JIS | EN DIN | EN IB | EN NF | ISO | GB |
---- | SCM421 | --- | --- | --- | ------ | 20 CrMnTi |
Cov ntaub ntawv muag khoom
Loj | Txoj kab uas hla: 10mm -1000mm Ntev: 5000mm-6000mm |
Keeb kwm | Ua hauv Suav teb |
Kev Xa Khoom | Kub dov, txias kos, forged |
Nto xav tau | Dub, sib tsoo, ci, polishing |
Kev kho cua sov | Quenched, Tempered, annealed |
Ntim | seaworthy packing, ntoo rooj plaub, thawv, woven hnab los yog ntawm cov neeg xav tau |
Lub sij hawm xa tuaj | Hauv 10-50 hnub |
Trade Term | EXW, FOB, CIF |
Kev them nyiaj | T / T lossis L / C thaum pom |
Chaw nres nkoj | Tuam Tshoj chaw nres nkoj loj, xws li shanghai, Dalian, Shenzhen chaw nres nkoj. |
MOQ | 1 Tuj |
Daim ntawv thov
20CrMnTi steel yog siv los tsim cov khoom tseem ceeb uas muaj kev kub ceev, nruab nrab lossis hnyav, cuam tshuam thiab kev sib txhuam nrog ib feem ntawm<30mm, such="" as="" gears,="" gear="" rings,="" gear="" shaft="" cross heads,="">
Cim npe nrov: 20crmnti iav steel bar
